Description
This close-coupled in-line pump has 2″ suction and discharge ports, allowing for in-line installation with system piping. The unit uses a 7.9″ nominal diameter impeller and a casing made from stainless steel, paired with a cast iron bracket and a bronze wear ring. The assembly includes a mechanical seal with a ceramic seat, carbon rotor, and EPT rubber, suited for fluid temperatures up to 250°F. The casing includes pressure tappings for differential readings and connects to the system with companion flanges.
The unit uses a 2 HP, 1750 RPM, ODP motor, operating on 115/208-230V, 60Hz, 1PH power. Maintenance-free operation is supported by permanently sealed, grease-lubricated motor ball bearings. Utilizing a rear pull-out design, the assembly permits complete removal of the motor and rotating components for servicing without disturbing the connected piping layout.
