Description
JET® Tools JEH Series Electric Hoists are designed for commercial and industrial applications.
- 24-volt push-button controller with cable strain relief system for durability and reliability
- Grade 80 black oxide-coated load chain for durability
- Heat-treated alloy steel geared drive train for long-lasting durability
- Upper and lower limit switches increase safety by preventing the load chain from over-travelling
- Equipped with slip clutch overload protection mechanism that prevents the hoist from lifting loads above its rated capacity
Technical Specifications
| Amperes | 23/11 |
|---|---|
| Capacity (lb.) | 4000 |
| Capacity (T) | 2 |
| Certificate Included | Yes |
| Standards | ANSI B30.16 standards, cUL |
| Duty Level | Heavy Duty |
| Duty Rating | 15 min/hr |
| Head Room | 28.15 |
| Hoisting Speed (FPM) | 9.8 |
| Horsepower (HP.) | 1.75 |
| Lift (ft.) | 20 |
| Load Chain Grade | 80 |
| Number of Falls | 2 |
| Number of Safety Hooks | 2 |
| Power Cable Length (ft.) | 20 |
| Power Source | 1 ph |
| Standard Chain Bucket | 2 |
| Voltage | 115/230 V |
| Country Of Origin | China |
