Description
Product details
| Gross weight | 9.8 kg | ||
| Net weight | 9.5 kg | ||
| Volume | 36.3 l | ||
| EAN | 5702427554474 |
Allocate codes for sales
| Customer Specific | No |
VLT® MICRO DRIVE FC 051 SERIES
| Product Group | VLT® Micro Drive FC- | ||
| Micro Drive Series | (051) 51 | ||
| Power Rating | (P22K) 22 KW / 30 HP | ||
| Phase | (T) Three phase | ||
| Mains Voltage | (4) 380 – 480 VAC | ||
| Enclosure | (E20) IP20 / Chassis | ||
| RFI Filter | (H3) RFI Class A1/B (C1) | ||
| Brake – Safe Stop | (B) Brake chopper | ||
| LCP | (X) No Loc. Cont. Panel | ||
| Coating PCB | (C) Coated PCB | ||
| Mains Option | (X) No Mains Option | ||
| Adaptation A | (X) Standard Cable Entries | ||
| Adaptation B | (X) No adaptation | ||
| Frame Size | M5-FRAME | ||
| Calculated Gross Weight | 9.8 | ||
| Calculated Net Weight [kg] | 9.5 | ||
| Division | 09 | ||
| Modelcode01 | FC-051P22KT4E20H3BXCXXXSXXX | ||
| Product Catalog | NO VIEW | ||
| Product Group | A79 | ||
| Product Hierarchy | 09A7960660673 | ||
| Product View (Switch) | Global (Standard) | ||
| Recommended Factory | Cannot Determine Vendor | ||
| Software Release | (SXXX) Latest release std. SW. | ||
| Typecode Part 1 | FC-051P22KT4E20H3BXCXXXSXXX | ||
| Vendor | Cannot Determine Vendor |
LCP Remote Mounting Kit,w/ 3m cable
Product details
| Gross weight | 9.8 kg | ||
| Net weight | 9.5 kg | ||
| Volume | 36.3 l | ||
| EAN | 5702427554474 |
Allocate codes for sales
| Customer Specific | No |
VLT® MICRO DRIVE FC 051 SERIES
| Product Group | VLT® Micro Drive FC- | ||
| Micro Drive Series | (051) 51 | ||
| Power Rating | (P22K) 22 KW / 30 HP | ||
| Phase | (T) Three phase | ||
| Mains Voltage | (4) 380 – 480 VAC | ||
| Enclosure | (E20) IP20 / Chassis | ||
| RFI Filter | (H3) RFI Class A1/B (C1) | ||
| Brake – Safe Stop | (B) Brake chopper | ||
| LCP | (X) No Loc. Cont. Panel | ||
| Coating PCB | (C) Coated PCB | ||
| Mains Option | (X) No Mains Option | ||
| Adaptation A | (X) Standard Cable Entries | ||
| Adaptation B | (X) No adaptation | ||
| Frame Size | M5-FRAME | ||
| Calculated Gross Weight | 9.8 | ||
| Calculated Net Weight [kg] | 9.5 | ||
| Division | 09 | ||
| Modelcode01 | FC-051P22KT4E20H3BXCXXXSXXX | ||
| Product Catalog | NO VIEW | ||
| Product Group | A79 | ||
| Product Hierarchy | 09A7960660673 | ||
| Product View (Switch) | Global (Standard) | ||
| Recommended Factory | Cannot Determine Vendor | ||
| Software Release | (SXXX) Latest release std. SW. | ||
| Typecode Part 1 | FC-051P22KT4E20H3BXCXXXSXXX | ||
| Vendor | Cannot Determine Vendor |
